Oil, Gas and Offshore Facilities
This article will examine how Heavy Duty VoIP Telephones can help improve maritime communications in offshore locations such as Oil & Gas Rigs, Floating Production Storage Offloading (FPSO) ships, Cargo ships, Tankers, Bulk Carriers, Container ships, Passenger ships, shipbuilding yards, Container Facilities, Machinery Monitoring Stations, Ports, Docks and other maritime areas. The document will also look at offshore IP networking issues that need to be evaluated when selecting industrial or emergency communications at sea including SIP (VoIP) offshore telephones, intrinsically safe / Ex and seawater resistant telephones.
A challenge for the Maritime Industry
Maritime facilities, vessels, ships, oil & gas platforms / rigs are notorious for their harsh environments where conventional communications are neither available or economically feasible. Brutal offshore climate and environmental conditions combined with remote and isolated locations means that communication lifelines are increasingly important to manage the ongoing fleet and vessel operations as well as maintain crew and passenger safety.
Oil and gas CIOs, CTOS, communications managers, network engineers and IT teams need to implement secure, fast and reliable communications systems to monitor drilling activity, track production and provide a ”ship-to-shore” communication to the corporate office onshore.
Beyond that, most ship operators have highlighted the importance of allowing crew to stay in contact with their family as a key contributor to a better quality of life on board. Offshore Communications are frequently named as one of the key drivers of crew retention as crews have come to expect their level of connectivity to Facebook, Skype, their online banking, and Netflix movies to match what they have at home regardless of where they are stationed. An oil and gas exploration vessel in the North Atlantic Sea outside Norway and a large-scale luxury liner crossing the Caribbean Ocean may be very different creatures, but they share a common need for vessel-to-land connectivity to transport VoIP voice and data traffic rapidly and reliably.
Each seagoing vessel - whether it is a large container ship, an oil tanker, or a luxury passenger liner – is dealing with many of the same communication challenges that any land-based organisation will be familiar with. The various segments – from commercial shipping, fishing industries and cruise liners, to naval and offshore oil and gas businesses – are looking at improving communications, from emergency telephones, providing employees with a better working environment, and utilising new applications that will help the business to run more profitably.
Finding the right maritime VoIP communications solutions for your vessel, with adequate bandwidth within budget, is therefore no small feat.
”Must-Have” Offshore Communications
High-performance marine communications is critical to keep remote offshore offices connected with decision makers around the clock.
Industrial and emergency telephones are often ”Must-Have” communication devices on board oil & gas rigs, Floating Production Storage Offloading (FPSO) ships, cargo ships, tankers, bulk carriers, container ships, cruise and passenger ships.
Emergency telephones, often referred to as a SOS telephones or Emergency Callboxes, are used in emergency situations offshore to notify a central control room about a fire, evacuation, entrapment or to issue Standard Marine Communication Phrases (SMCP). SMCP is a set of key phrases in the English language (which is the internationally recognised language of the sea), supported by the international community for use at sea and developed by the International Maritime Organization (IMO). An example of a SMCP could be the message: "I have developed stability problems, heavy icing. Request ice breaker assistance”, or “I am sinking. Please proceed to my assistance. What is your ETA at our distress position?”.
The importance of effective onboard communications was highlighted to the world in 2010, when the Deepwater Horizon oil spill happened in the Mexico gulf outside of the USA. At a critical time when offshore vessels, coast guard & rescue services needed to communicate effectively together, many onboard emergency telephones were found not to be working. This resulted in a focus to improve maritime communications onboard ships and offshore oil & gas rigs by investing in the latest marine VoIP Telephones. This initiative is a joint effort from both governmental emergency response teams, service providers, Oil & Gas rig owners and operators.
In summary, to maintain communications in emergency situations at sea, whether it is accidents, sudden illness, personal injury or other emergency situations, it is critical to invest in dependable and rugged VoIP telephones in your offshore environment.
High Performance Marine VoIP Telephones
Norphonic is a Norwegian company that specialise in the production of high performance communications for offshore and marine areas. Being located in the seaport of Bergen on Norway’s west coast, the company has a long history of delivering Heavy Duty VoIP telephones into some of the world’s most challenging areas, ensuring essential voice communications when it is most needed.
The Norphonic Offshore SIP-based Telephone is an industrial /maritime communications unit that is both seawater resistant and weather proof to IP65. This marine Ethernet telephone is extremely robust and the hook-switch has no moving parts, making it able to operate in industrial dirty or exposed marine areas where icing, dust or grime quickly can become a problem.
In the remaining part this article we shall look at some of the issues that needs to be addressed when selecting an effective VoIP / SIP telephone solution in your maritime communications needs offshore.
VoIP Telephones & Offshore Fiber Networks
As with all major modern day industrial networks, there is a shift happening in Maritime Industry towards implementing modern fiber / Ethernet networks. In previous years, the industry typically viewed cruise or ship Ethernet networks as ”IT infrastructure” and saw this primarily as a cost center. However, today rugged and heavy duty VoIP telephones represent a highly cost effective way for rig & ship owners to future-proof their fiber network for expansion using open standards whilst improving their offshore communications.
Ship owners with multiple ships in different geographic locations need the ability to communicate between offices in a cost effective way, and traditionally calls over the PSTN and GSM networks could easily ramp up heavy monthly bills.
Reduce monthly bills by routing calls over the internet
A benefit with the Norphonic Offshore VoIP Telephone is that it is based on open SIP standards. This means that you can use the Norphonic SIP function and transfer the calls to any IP PBX free of charge over the internet. Using open standards also means that the Norphonic solution is extremely cost effective when it comes to future maintenance and repairs. -You can easily swap out the Norphonic SIP phone or PBX at a later date, without having to worry about being tied to certain phone or switch products via proprietary protocols. Session Initiation Protocol (SIP) is the most widely used protocol for controlling multimedia communication sessions such as voice and video calls over Internet Protocol (IP). For example, if you need to change from an Alcatel solution to a Cisco PBX solution or telephones at a later date, you can do this without having to worry if you need to change out any other infrastructure.
In addition, by Norphonic maritime VoIP telephones, there are cost savings to be gained from remote system monitoring, fault checks and automatic reporting.
Ship to Shore Communications
Norphonic units communicate over an industrial Ethernet. The flexibility of Ethernet network topology allows a ship network to be configured to provide the level of fault tolerance required of the application. Below is an example on how Norphonic maritime VoIP telephones can be used to make ship-to-shore calls on board oil & gas rigs, Floating Production Storage Offloading (FPSO) ships, cargo ships, tankers, bulk carriers, container ships, passenger ships etc.
Fig.1. The image shows how the Norphonic Marine VoIP telephone can be connected to the Antenna via a Ku Band Satellite, providing Internet access 24/7 through an onshore operations Hub station.
Offshore LAN / VoIP Network
On board the ship, Norphonic units can operate effectively on a range of network topologies via single mode fiber cables or wireless connections. The simplest option is a star network configuration with all modules radiating out from a single switch. At the other extreme is a fully managed redundant ring network, where any single point of failure can be managed through an alternate pathway. The Norphonic IP Maritime Seaproof Telephone comes with an option to include two built-in single mode fiber optic ports (LC Connectors) which enables redundant networking via Rapid Spanning Tree Protocol (RSTP). This means that you do not need an external fiber switch to enable redundancy, which is a highly cost effective inclusion. The phone could also be used in a network with external switches, and the phone would then be connected to the switch via Ethernet (RJ45) port on the Norphonic maritime VoIP telephone unit.
Example - Offshore LAN / VoIP Network
The below figure shows how the telephones could be installed in a ring-formation to provide a high degree of redundancy in case of failure of either the fiber link or the phone itself.
Fig 2. A redundant VoIP Network using Norphonic’s integrated single mode fiber ports.
Explanation of Network Redundancy (fig. 2.)
Since the Norphonic sea-proof telephones can be equipped with 2 fiber ports as a product option, a break in the fiber link in one direction will not affect the phone, since the system will reconfigure to the
alternate path. And if one of the telephone is faulty, it will not affect the other phones from functioning.
In many modern ship / offshore networks, it is required that the offshore network shall be made to be redundant, immune against noise and built on open standard protocols. This is achieved by use of Ethernet over fiber, usually coupled in a ring formation with a protocol which controls the ring. Of open protocols, typical alternatives include Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP). Norphonic onboard VoIP telephones support RSTP and STP. Today, STP is rarely used, so in practical terms RSTP is the main protocol which is used. Seeing that almost all administration switches today support RSTP, this means that you can construct network rings where you can mix and match different Ethernet switches from different manufacturers, and you can also be free to select whatever switch you want when you are upgrading or maintaining your network. Norphonic does not support proprietary solutions, as we cannot see that a customer will have any benefit by being bound to only one product. This means that you secure a high degree of future proofing when investing in a Norphonic Maritime VoIP Telephone solution.
The Norphonic VoIP Telephones are otherwise built on Open Standard SIP (Session Initiation Protocol) which is the most widely used VoIP Signalling protocol and RTP (Real Time Protocol) which is the most widely used Audio protocol on VoIP networks. This further establish the Norphonic unit as the telephone of choice when it comes to future-proofing your overall maritime communications solution.
Offshore Wireless Communications
When designing a wireless network offshore, it is important to have a basic understanding of radio receivers/transmitters and the modulation and coding used to convey information in existing and emerging communications systems. This can include the latest generation of receivers, transmitters and modulation systems used in mobile radio, microwave, satellite WiFi, WiMAX, HSPA and LTE and other OFDMA/ FDMA/TDMA systems. It is also important to plan well when implementing offshore wireless networks, as some equipment on board the ship can pick up and reflect signals.
Although the Norphonic VoIP offshore telephones are typically interconnected to the Ethernet network using fiber cables, Norphonic IP telephones can also be connected to an external WiFi transceiver / antenna in order to transmit and receive signals, thereby providing a Wireless solution for Offshore / Marine areas. See the example schematic below.
Fig 3: Example of a Norphonic offshore VoIP telephone connected to a multi-directional transceiver / antenna to facilitate Wireless / WiFi communication in offshore / maritime areas, on board ships etc.
The flexibility of the Norphonic VoIP Marine Telephones therefore means that it can either be used on a fixed fiber cable layout or in a wireless VoIP environment. There are no particular barriers to installing Wireless / WiFi solutions, but the network designer should be aware of potential voice quality pit-falls and plan for these.
Noise Reduction and Voice Quality
Passengers and crew have a certain voice quality expectation when conducting a telephone conversation. This expectation is no different when using offshore VoIP telephones compared to using their fixed line telephone at home / onshore.
Some key things to be aware of in terms of voice quality when designing your ship network layout:
• Latency - delay from data is transmitted until it is received. Noticeable in conversations if latency goes above 100ms.
• Jitter - variances in latency between packets. High jitter means large variance in packet latency and degrades speech quality
• Out of order data-packets - degrades speech quality, is often caused by jitter
The offshore network designer should be careful to specify a VoIP Telephone which gives a good sound quality, by ensuring that the telephone incorporates the following:
- Quality of Service (QoS) is a feature found in all Norphonic VoIP marine telephones and refers to the ability to provide different priority of voice and data flows, or to guarantee a certain level of performance to a data flow, ensuring impeccable delivery of voice communications in an IP network.
- Type of Service (ToS) is a feature found in all Norphonic VoIP marine telephones, delivering packet precedence (i.e., priority) in network traffic, thereby ensuring low delay, high throughput and high reliability.
Voice Quality - Mean Opinion Score (MOS)
Mean Opinion Score (MOS) is a metric calculation which is used to measure call / voice quality. The MOS score of a call is measured numerically between 1 (for unusable) and 5 (for excellent). VOIP calls that are working properly fall between 3.5 and 4.2 MOS. A score of 4.0 is defined as toll quality. MOS score is an indication of what users would think about the call. It was developed using surveys of users of different technologies, but today it is calculated through the use of engineering formulas.
When designing industrial or offshore IP networks to carry voice, you should not allow the MOS to drop below 3.0 at any time. For most emergency network applications, a MOS above 3.7 is recommended at all times. The Norphonic Heavy Duty VoIP Telephone can boost a high MOS listening quality score of 4.3.
Remote Management and Control
As the Offshore VoIP Telephone installations are geographically dispersed and the number of remote users changes over time, the need to manage and support vital VoIP devices from afar becomes crucial.
With Norphonic rugged maritime VoIP telephones, operators the central operations hub can configure, monitor and even trouble-shoot Norphonic telephones from a remote location. This functionality is highly useful for oil & gas rigs, Floating Production Storage Offloading (FPSO) ships, cargo ships, tankers, bulk carriers, container ships, cruise and passenger ships. This web-browser solution is very easy-to-use and has been designed to provide the ship operator or rig owner with complete control.
In terms of start-up configuration, Norphonic sea-proof telephones can also be commissioned from a remote location. The telephones can be configured either via Web interface or via configuration files. In case of the latter, a configuration file for each phone is placed on a TFTP server, and upon boot-up, phones retrieve the configuration. If the TFTP server is not accessible (e.g. removed after initial site configuration), telephones use the settings downloaded previously. All configuration and firmware updates can be done remotely over the network, including re-starting telephones. Firmware update is performed by placing an update bundle on TFTP server. The phones on the installation detect new firmware and perform the upgrade within 24 hours, with normal distribution in the time frame. This avoids peak loads on the network, avoids RSTP tree deterioration due to mass reboots of equipment, and ensures that only a fraction of the telephone park will be down at any given moment. This is a great benefit for the end user regarding ensuring optimal Mean Time Between Failure records
Self-Monitoring and Fault Check Functions
To further reduce maintenance costs and improve overall system up-time, Norphonic offers automatic health-checks and fault sensing on all offshore models. This valuable feature gives the ship operator an immediate notification if there is a connectivity or function fault with the Norphonic unit, thereby ensuring timely repair and maintenance of your maritime communications system. This beneficial function offer surveillance capabilities of:
- Hook sensing (ie: hook off/on)
- Audio Self Test (microphone / headset check)
- Fiberport 1 status (link check)
- Fiberport 2 status (link check)
- RJ 45 port status (link check)
- Firmware version and firmware update status
The audio self-test involves testing the function of the SIP software, audio circuits and the handset by playing and recognizing a set of DTMF tones in the handset at pre-configured time intervals. The alarms are reported over the fiber optic or cat5 Ethernet (where applicable). The phone can provide Modbus UDP, Modbus TCP or SNMP traps for the self test and on-hook / off-hook event. Fiber link failure does not generate a trap but it can be polled. The advantage of using SNMP or Modbus protocols is that these are standardised tools for monitoring other network equipment, including switches, routers, PBX systems, VoIP gateways and pretty much anything you
want to monitor inside an offshore environment.
SCADA or Business Process Management Integration
The inclusion of Modbus TCP, UDP and SNMP open standard protocols in all Norphonic VoIP models mean that it easy to integrate Norphonic offshore telephones with your existing ship SCADA system or overall data reporting system.
Norphonic Heavy Duty VoIP Telephones can therefore easily integrate with existing IT infrastructure such as business process management, SCADA systems or land based control equipment. This provides unique flexibility when integrating process-reported alarms.
What to look for in a VoIP Offshore Telephone?
There are many issues that needs to be addressed prior to commissioning an IP sea-proof telephone, such as evaluating the installation environment, functionality and temperature ranges. Below are some key pointers to look at when choosing your VoIP Offshore Telephone:
- Is the system future proof? Can the system be upgraded or changed in the future without having to change all the telephones and the entire network? All Norphonic Heavy Duty telephones can be changed with other systems without loss or differentiation to the level of service.
- Is the telephone dust and water proof? Offshore and maritime areas are some of the most challenging areas in the world, exposed to extreme levels of dust and water. The ingress IP rating to IP65 is therefore recommended in all offshore applications. See definition of Ingress Protection in the below Glossary for further information.
- Is the telephone seawater resistant? All Norphonic VoIP telephones are high performance products which are coated with a protective solution paint, making it resistant to corrosion from the seawater.
- Is the telephone condensation proof? –This can otherwise lead to severe problems in operation as water can easily form inside the unit, affecting performance. All Norphonic telephones are immune to condensation effects.
- Does the hookswitch contain moving parts? All Norphonic Heavy Duty VoIP telephones do not contain moving parts, and can therefore operate in extreme areas where dust or exposure to grime is a challenge for traditional telephone systems.
- Can the system work in extreme temperatures? Offshore environments can be notoriously hot and/or cold, so a wide operating temperature functionality is recommended for offshore telephones, from –20 up to +55 Celcius.
- Does the telephone incorporate VSQ - Voice Sound Quality? This is a standard feature in all Norphonic telephone systems, ensuring loud and clear sound, even in noisy ambiance areas.
- Does the VoIP telephone incorporate a QoS – Quality of Service functionality and ToS – Type of Service? These features, found in all Norphonic telephones, guarantees a certain level of performance in a data flow, ensuring impeccable delivery of voice communications in an IP Network.
- Is the telephone colored in such a way that it is easily identified by users? The Norphonic Heavy Duty VoIP comes in a bright yellow color as standard. Colors can also be customised depending on the user needs and order volumes.
- Is the system easy to install and to maintain? Norphonic Heavy Duty VoIP telephones are easy to install and have in-built status monitoring and fault check functions. This means that the status of the telephones can be monitored from a remote location, saving you considerable maintenance costs.
- Can the onboard communications technology easily be integrated with the existing land-based corporate IT infrastructure? Norphonic Heavy Duty VoIP systems are built on Open Standard SIP technology & Open Standard Modbus TCP / UDP technology, and can therefore be integrated with your existing IT infrastructure, SCADA systems or any IP based PBX and network system (including Alcatel, Cisco, Asterisk, Switchvox, Broadsoft etc).
- Is the telephone CE approved? CE marking means that the product is certified to meet EU consumer safety, health or environmental requirements. End users should be aware that some telephones use the intentionally confusing term ”CE” for ”China Export”, and the only way consumers can check this is to closely examine the CE mark/ logo as the two logos are very similar.
- Do you need an Ex approved telephone or not? It is important to realise that not all oil & gas locations actually need EX or explosion proof telephones. This depend on whether or not your area is unsafe / ie. exposed to explosive gases, vapor or other hazardous elements. It is worthwhile to consider this before you purchase an explosion proof system as EX telephones / Intrinsically safe telephones will be more expensive than ”regular” industrial VoIP telephones.
- In the cases where explosion-proof telephones are needed, is the EX telephone approved to the correct standards? In Europe, the ATEX directive consists of two EU (European Union) directives describing what equipment and work environment is allowed in an environment with an explosive atmosphere. ATEX derives its name from the French title of the 94/9/EC directive: "Appareils destinés à être utilisés en ATmosphères EXplosibles". Oil & Gas & related ship owners must follow the directives to protect employees from explosion risk in areas with an explosive atmosphere and also classify areas where hazardous explosive atmospheres may occur into zones. The classification given to a particular zone, and its size and location, depends on the likelihood of an explosive atmosphere occurring and its persistence if it does. In other geographies like USA, MSHA (Mine Safety Association) has spesifications on explosion proof phones, and different approval bodies can issue different approval certificates. For example Underwriters Laboratories (UL) and Factory Mutual (FM) issue approvals in the USA, and Canadian Standards Association (CSA) issue approvals for Canada. In other words, if you need EX products, it is important that you check what approvals is needed in your region, and follow local regulations on this important safety aspect.
Contact Info - Maritime Communications Technology
The maritime sector is a diverse one which includes commercial shipping, fishing industries, leisure shipping and cruise, naval, as well as multinational oil and gas industries. The degree to which the shipping and maritime industry can improve communications and reduce costs to depends on how well they exploit the full communication capabilities of industrial VoIP Ethernet products including Ex and rugged VoIP Telephones.
To meet growing demands for reliable and cost-effective communications, Norphonic is offering its Heavy Duty VoIP Telephones for offshore and maritime areas. Norphonic is a highly affordable maritime VoIP telephone which is able to operate in harsh offshore environments.
You can read more about Norphonic and access case studies, white papers and technical product on this webpage.
We also encourage you to get in touch to find out more about Norphonic VoIP Maritime Telephones. You may also contact us at: Norphonic AS, Fabrikkgaten 10, 5059 Bergen, Norway, Tel: +47 5562 7520, Fax: +47 55590516, Email: firstname.lastname@example.org or via the contact section on www.norphonic.com
